Product Details:
|
Name: | Mobile Protector Laser Machine | Keyword: | Cellphone Protector |
---|---|---|---|
Item: | Mobile Skin Design Machine | Cutter Type: | CO2 Water Cooling Cutter |
Cutting Area: | 25*35 CM | Control Software: | Daqin Design Program |
Applicable Industries: | Repair Store, Retail Shop, Online Store, Kiosk | Weight: | 32KG |
Usage: | Tempered Glass Protector | Applicable Material: | Nano Glass, TPU, Plastic, PVC |
Highlight: | daqin mobile tempered glass cutting machine,tablet mobile tempered glass cutting machine |
DAQIN automatic laser cutting machine, which is controlled by the professional design and management software that can cut kinds of protectors and skin for cellphone, tablet, laptops, smartwatch and so on. It solves the problem of supply screen protectors of small batch. The curve of cutting is natural and without rough edge.
1. Customers can add and designs new model cutting template by themselves, or can contact our after sales team that we will add the deisgns directly.
2. Mobile screen protector cutting system = mobile screen software + mobile screen protector cutting machine
3. The DAQIN app owns abundant template data, and it's upgrading online. It is including the latest models of mobile phones and tablets, any model, any shape, any brand for it.
4. Free arrangement, automatic positioning, saving cutting material effectively.
5. Easy operation, powerful functions. Tempered glass screen protector machine controled by professional software.
6. More Than 10000+ Cutting Templates for Mobile Phone Screen Protective Film, keep on upgrading The Newest Templates.
Specification for Daqin Mobile tempered glass screen protector Laser Cutting Machine
Specification of C188 Laser cutting machine | |||
Laser Type | CO2( laser tube ) | Laser Power | 30W |
Laser Power Supply | 40W | Air Pump (Built-in) | DC12V |
Water Pump (Built-in) | DC24V | Exhaust Fan (Built-in) | DC12V 1.74A |
Radiator | DC12V 0.20A | LED light | DC12V |
Cooling Way | Circulating water cooling | Smoke Exhaust Way | Rear Exhanst |
Driving Mode | 0.9°Stepper Motor | Transport Interface | USB Cable |
Cutting Precision | ±0.01mm | Cutting Speed | 0-50mm/s |
Operating Ambient Temperature | 5~45℃ | Power Supply | 110 V- 220V |
Maximum Cut Area | 360x250mm | Machine Dimension | 710x570x235mm |
Machine Weight | 27kg | Total Power | 700W |
Packing Size | 87*72*35 CM ( 44kg ) | Total Packing Weight | 40 KG |
The maximum cutting area is 250mm*360mm, you can cut screen protector for mobile, tablets, laptop, gaming, camera and so on.
Especially phone back skins. We support all kinds of nano glass, hydrogels (tpu soft film), vinyls( phone back skin materials). You can also do engraving.
We have many kinds of materials of different quality, and prices.Don’t need to worry about the inventory any more,
You can cut according to customer need, cut at side for retail or wholesale. The cutting is smooth without burrs.
All accessories (air pump,water pump, exhaust fan) all built-in, more neat and saves space. We have professional tech team for templates making, accurate and various. Support multiple templates cutting at the same time make cutting more efficient. You can edit your own templates, such as templates for camera, car mirrors,UV and so on. The software includes nearly all mobile phone brands in markets which supports update new models timely.
Market Value
Materials Details:
Antishock tempered glass film 9H |
Highly recommended thick glass layer, smooth surface
and anti-drop;super strong adsorption, easyto paste.
The thickness of the glass layer is 0.2mm, which is
two-thirds of the thickness of the used layer; 4 layersin
total, the surface is blue; the bottom layer is
transparent (two layers).
|
Black Tempered Glass Film |
1. Good fit, fast exhaust, no white edge.
2. It can be bent at 360°, with high light transmittance
and no broken edges.
3. Advanced nano-explosion-proof technology, up to
9H resistant to explosion and explosion, strong impact
resistance.
4. Anti-fingerprint waterproof treatment, touch effect
is more sensitive.
5. using layer thickness 0.3MM
|
YT TPU protection film |
This product is a HD curved screen protector, the
middle matte is the use layer, the surface is a yellow
protective layer, and the bottom layer is transparent and
hard. The intermediate HD layer thickness is
0.2mm, which can protect the mobile phone with the
whole machine. It is strong in glue, suitable for large
radius mobile phone screen, without warping and
curling, perfect fit;summer explosion, anti-glare anti
fingerprint, not afraid of sweat. Game Player preferred.
|
Main Features
FAQ about Mobile tempered glass screen protector Laser Cutting Machine
How about the Warranty and Training for laser mobile screen protector cutting machine ?
* The warranty for the machine is 1 year.
* The machine has been tested by professionals and has 18 years of practical application.
It's with high stability and low fault rate.
* Detailed training video for the machine and software will be provided.
Professional after-sale service is available by remote assistance and video chatting.
The operation is easy to learn, everyone can be a master.
How about the delivery time and shipping way for tempered glass cutting machine?
* Since the packing is with small volume and light weight,
usually the goods will be shipped by international express company, such as DHL, FEDX...
need about 2 days for preparing and packing the goods.
