Product Details:
|
Cutter Type: | Laser Cutter | Control Software: | Daqin Laser Cut Software |
---|---|---|---|
Usage: | Tempered Glass Screen Protector | Applicable Material: | Leather, Tpu, Plastic, Wood,pvc,Nano |
Function: | Cutting,Marking | Name: | TPU Nano Glass Film Automatic Laser Cutter |
Keyword: | TPU Nano Glass Film Automatic Laser Cutter | Use: | Notebook, Mobile Phone, Camera, |
Introduction of TPU Nano Glass Film Automatic Laser Cutter
Introducing our cutting-edge mobile phone screen protective film cutting machine, equipped with over 8000+ cutting templates to cater to all your needs. Our team keeps on upgrading the newest templates to ensure you have the latest designs at your fingertips. With our professional templates design software, you can have full control over your mobile phone screen protector production.
Not only can you cut screen protectors for mobile phones, tablets, watches and cameras, but you can also create phone back skins protectors. Our machine spares, including water pump, air pump, and exhaust fan, are all built inside the machine, saving you more space.
Our machine offers multiple operation models, including a smart phone app wireless operation and PC/tablet software operation, making it more convenient for you. Invest in our machine today, and elevate your mobile phone screen protector production to a professional level.
DAQIN TPU Nano Glass Film Automatic Laser Cutter
Nano Tempered Glass / Hydrogel Film Screen Protector / TPU Film Screen Protector / PET Film Screen Protector / Vinyl Paper Sticker / Plastic/Metal Engraving... All can be cut !Specification for TPU Nano Glass Film Automatic Laser Cutter
Specification of TPU Nano Glass Film Automatic Laser Cutter | |||
Laser Type | CO2( laser tube ) | Laser Power | 30W |
Laser Power Supply | 40W | Air Pump (Built-in) | DC12V |
Water Pump (Built-in) | DC24V | Exhaust Fan (Built-in) | DC12V 1.74A |
Radiator | DC12V 0.20A | LED light | DC12V |
Cooling Way | Circulating water cooling | Smoke Exhaust Way | Rear Exhanst |
Driving Mode | 0.9°Stepper Motor | Transport Interface | USB Cable |
Cutting Precision | ±0.01mm | Cutting Speed | 0-50mm/s |
Operating Ambient Temperature | 5~45℃ | Power Supply | 110 V- 220V |
Maximum Cut Area | 360x250mm | Machine Dimension | 710x570x235mm |
Machine Weight | 27kg | Total Power | 700W |
