Product Details:
|
| Item: | Laser Screen Cutter | Control Software: | Daqin Laser Cut Software |
|---|---|---|---|
| Applicable Industries: | Repair Shops, Retail Shop | Laser Type: | CO2 |
| Weight: | 30KG | Packing Size: | 87*72*35 CM |
| Usage: | Tempered Glass Screen Protector | Applicable Material: | Leather, Tpu, Plastic, Wood,pvc |
| Function: | Cutting Screen Protector | Name: | Daqin Pet Tempered Glass 9h Anti Shock Screen Protector Cutter 40*60cm Working Area |
| Laser Power: | 30W / Customized | Power Supply: | 110 V- 220V |
| High Light: | 9h screen protector cutter,anti shock screen protector cutter,anti shock screen guard cutting machine |
||
Specification for Daqin Pet Tempered Glass 9h Anti Shock Screen Protector Cutter 40*60cm Working Area
| Specification of C188 Laser cutting machine | |||
| Laser Type | CO2( laser tube ) | Laser Power | 30W |
| Laser Power Supply | 40W | Air Pump (Built-in) | DC12V |
| Water Pump (Built-in) | DC24V | Exhaust Fan (Built-in) | DC12V 1.74A |
| Radiator | DC12V 0.20A | LED light | DC12V |
| Cooling Way | Circulating water cooling | Smoke Exhaust Way | Rear Exhanst |
| Driving Mode | 0.9°Stepper Motor | Transport Interface | USB Cable |
| Cutting Precision | ±0.01mm | Cutting Speed | 0-50mm/s |
| Operating Ambient Temperature | 5～45℃ | Power Supply | 110 V- 220V |
| Maximum Cut Area | 360x250mm | Machine Dimension | 710x570x235mm |
| Machine Weight | 27kg | Total Power | 700W |
| Packing Size | 87*72*35 CM ( 44kg ) | Total Packing Weight | 40 KG |
The maximum cutting area is 250mm*360mm,
You can cut screen protector for mobile, tablets, laptop, gaming, camera and so on.
Especially phone back skins. We support all kinds of nano glass, hydrogels (tpu soft film),
vinyls( phone back skin materials). You can also do engraving.
We have many kinds of materials of different quality, and prices.Don’t need to worry about the inventory any more,
You can cut according to customer need, cut at side for retail or wholesale.
The cutting is smooth without burrs.
All accessories( air pump,water pump, exhaust fan) all built-in , more neat and saves space.
We have professional tech team for templates making, accurate and various.
Support multiple templates cutting at the same time make cutting more efficient.
You can edit your own templates, such as templates for camera, car mirrors,UAV and so on.
The software includes nearly all mobile phone brands in markets
which supports update new models timely.
